Description
FOX 2.0 IFP Rear Shock Features:
- Race-proven damping control for comfortable on and off-road driving
- Aluminum body to increase cooling capacity
- IFP mono-tube design
- Maximizes performance and eliminates oil aeration
- Bolt-on easy installation
- Handles tough off-road environments
- Limited one year warranty
Greatly Improves Suspension Performance While Dramatically Reducing Fade
The standard shock that come on your 1999-2016 F250 or F350 Super Duty just aren’t cut out for extremely aggressive off-roading, which makes the extra ground clearance from big tires kind of moot. Well, our friends over at Fox Shocks have a solution for you with this Performance Series 2.0 IFP Rear Shock for Super Duty’s at stock ride height to 1″ of lift. This shock is a leaps and bounds improvement over typical white-body shocks, and even performance shocks that are included in some lifts. The Fox 2.0 features an internal IFP mono-tube reservoir design that separates shock oil from the high-pressure nitrogen.
2″ Diameter Aluminum-Body Shock
The Fox 2.0 IFP Shock bolts onto your Super Duty. The shock itself is 2″ in diameter with an aluminum body that improves cooling capability over the majority of steel-body shock on the market. Each shock has a 5/8″ chrome-hardened shaft and valving that’s been finely tuned to offer your truck excellent off-road performance with making your street ride too harsh. The shock mounts are made out of CNC machined billet aluminum and come standard with nitrile rubber bushings that resist more deflection than stock, but are still extremely quiet.
Rear IFP Shock Specs:
- Body Plating: Clear-anodized for durable finish
- Reservoir: Internal IFP mono-tube reservoir design
- Components: Black anodized, CNC-machined 6061-T6 billet aluminum
- Shaft: 5/8″ hard-chrome plated heat-treated alloy steel
- Piston: Race-developed high-flow piston design
- Valving: Application specific valving to maximize performance
- Seals: Redundant sealing pack system main seal, wiper seal, scraper seal
- Bushings: Quiet nitrile rubber for increased suspension articulation
- Extended: 30.120
- Compressed: 18.500
- Travel: 11.620
- Top/Bottom Mount: Eyelet
Vehicle Fitment: 1999-2016 Ford F250/F350 Super Duty 4WD
