Description
Highlights:
- Reliable pulling power for any application
- Fully sealed case with IP68 rating
- Series wound motor with 3-stage geartrain
- Unique wireless remote
- Standard 10×4.5″ bolt pattern
- Backed by a Limited Lifetime Warranty
Highly Reliable Winch with Braided Steel Cable
Getting yourself unstuck when you’re out in the bush is never fun, but when it happens, you’re going to need a winch system that won’t let you down. The Warn Zeon 12-S Platinum Winch gives your off-road vehicle of choice 12,000lbs worth of pull in one of the most reliable winch packages on the market. The Warn Zeon 12-S Platinum winch combines a smooth geartrain, powerful motor, and heavy-duty construction with an 80ft Spydura Synthetic Rope that all come together to make a winch that can get you out of just about any jamb while you’re out on the trail. The Warn Zeon 12-S Platinum winch features a standard 10×4.5″ bolt pattern and come with a wireless remote that makes it a breeze to operate the winch.
Fully Enclosed and Waterproof Case with Reliable Motor
The Warn Zeon 12-S Platinum was built from the ground up to provide reliable and consistent winching performance in nearly any condition or application. The winch is built around a powerful series-wound 12V motor that’s capable of a 5.6 foot-per-minute line speed and is fully-sealed within an IP68-rated case. The case itself is fully enclosed and comes standard with a black powder coat finish to protect against corrosion. Each winch comes standard with a large-diameter drum that’s still extremely lightweight to maximum efficiency and pulling power. The 3-stage planetary gear train features a 162:1 reduction ratio while a class-leading cone braking system provides automatic braking with low levels of heat. The winch comes standard with 80ft of 3/8″ diameter Warn Spydura Synthetic Rope as well as a complete hawse fairlead to help with installation. Specifications:
- Rated Line Pull: 12,000lbs
- Geartrain: 3-stage planetary
- Gear Ratio: 162:1
- Clutch: Freespooling rotating ring gear
- Brake: Mechanical Cone
- Drum Diameter: 3.15″
- Drum Length: 9.3″
- Rope: Synthetic. 80ft x 3/8″ diameter
- Fairlead: Hawse fairlead
- Recommended Battery: 650 CCA Minimum
- Battery Leads: 72″
- Dimensions: 24.25″ x 7.14″ x 10.52″
- Bolt Pattern: 10″ x 4.5″
