Description
TK119177-2PK Complete Bundle Kit
Complete kit bundle containing all necessary components for your project. Professional-grade components designed for reliable performance and long-lasting durability.
This Kit Includes:
• 2x Tekonsha ModuLite HD Protector w/Integrated Circuit & Overload Protection & 5-Flat Connector for Backup Light or Surge Brake Lockout Circuit (TK119177)
What’s Included:
Tekonsha ModuLite HD Protector w/Integrated Circuit & Overload Protection & 5-Flat Connector for Backup Light or Surge Brake Lockout Circuit Part #TK119177Qty: 2
Brand: Tekonsha
ModuLite HD Protector w/Integrated Circuit & Overload Protection & 5-Flat Connector for Backup Light or Surge Brake Lockout Circuit
Description
Does your trailer have multiple tail lights or does the tail lights seem dim to you? Then it is possible you need a Modulite from Tekonsha. The Tekonsha Modulite product line has power modules designed to virtually eliminates additional electrical draw on the vehicle’s tail light circuits. They help to ensures maximum trailer light brightness for your trailer tail lights. It powers the trailer’s stop, turn, tail and running lights without overloading your vehicle electrical systems.
- The unit is rated for up to 4.2 amps for Turns/Stops circuits and 7.5 amps for the Taillight circuit and 4.2 amps for Back-Up circuit
- Draws power directly from the vehicle battery and uses less than 5mA of the vehicle circuit for sensing to turn the trailer functions on and off
- Will work with either LED/Incandescent bulbs (vehicle & trailer)
- Has integrated re-settable Short Circuit and Overload protection, to safeguard itself and the tow vehicle from shorts and installation wiring mishaps
- Designed not to send feedback thru the vehicle circuits
- The trailer brakes will override the hazard lamps when the brake is activated
- The taillight circuit has been upgraded to work with vehicles that use a pulse width modulation (PWM), this will allow the converter to turn on fully and gives the trailer lights full brightness during activation
- Will work with most vehicles that have a multiplex system for lighting
- Will not work with vehicles with low-side switch
- Integrated 5-flat electrical wiring connector. Fifth circuit added for surge brake lockout or backup light circuit on trailers (some units will come with a 5-way cap. Mounting bracket sold separately)
- Can be used on a 2 wire or 3 wire system
- All solid-state components in potted encapsulation
- Includes integrated protective cover
Specifications
| BRAND: | TEKONSHA |
| PART NUMBER: | 119177 |
| WARRANTY: | LIMITED 1 YEAR WARRANTY |
| WEIGHT: | 1.19 LBS |
| UNIVERSAL OR SPECIFIC FIT: | UNIVERSAL |
| TERMINAL QUANTITY: | 4 |
| WIRING HARNESS INCLUDED: | YES |
| CONVERTER TYPE: | Powered |
| CONNECTOR SHAPE: | RECTANGLE |
| ILLUMINATED: | NO |
Product Video
Bundle Benefits & Features:
- Complete Kit Solution – All components included for your project needs
- Quality Assurance – All genuine parts with manufacturer warranty
- Cost Savings – Bundle pricing saves money versus individual purchases
- Professional Installation Ready – Matching specifications eliminate fitment issues
- Time Efficient – One-stop solution reduces ordering complexity
- Compatibility Guaranteed – All components tested for compatibility
Product Specifications:
- Kit Type: Complete Bundle Kit
- Components: 1 Professional Grade Parts
- Application: Industrial & Professional Use
- Warranty: Manufacturer Warranty Included
- Compatibility: Designed for Optimal Performance
