Description
Compatible with 2020 Jeep Wrangler 2.0TFor 2020 Wrangler 2.0L Turbo owners who want serious horsepower gains, sharper drivability, and off-road-ready performance, the Trinity T2 Platinum + Unlocked PCM Kit is the ultimate upgrade.
- 2020 Jeep Wrangler JL 2.0T
- Target Cooling Fan temps can be set from 150°-230° for use with cooler t-stat
- Tire Size Adjustment 20”-44”, allows for correcting speedometer for different tires
- Add 25-30 rwhp over stock on premium fuel
- Up to 30 hp and 30 ft/lbs torque on 93 octane
- WOT Fuel Adjustment – 1-7K RPM +/- 20%, allows for fine tuning Air/Fuel Ratio
- WOT MBT Spark 1-7K RPM +/- 10
- WOT Spark – 1-7k RPM +/- 10
- Tunes for 87, 91 and 93 octane fuel provided
- Performance TCM tune included
- Factory Modified PCM that allows a 15+ Chrysler vehicle to be tuned
- Read/clear DTC codes
- Installation is simple and only takes about 10 minutes
- Includes PCM programmed to your vehicle and Trinity 2
- No vehicle downtime for tuning!
- Preloaded with multiple performance tunes
- Customizable gauge layouts
- Upload your own background images
- Adjust Rev Limiter in Drive/Neutral by +/- 500 RPM
- Disable Traction Control/ESP
- Raise or Lower Idle Speed by +/- 400 RPM
- Required bypass module is included
- Speed Limiter On/Off enabling increased top speed
Information:
Not compatible with 2.0LT with Etorque. For E-torque, or electric-gas 2.0L hybrid application use PCM-JL20ETQ20-T2
Application Summary:
| Year | Make/Model |
|---|---|
| 2020 | Jeep Wrangler |
| Attributes | |
| 5 Volt Data Logging Inputs | Yes |
| 5 Volt Data Logging Inputs | Yes |
| 50 State Legal | No |
| AC Adapter | No |
| Accepts Custom Tunes From CMR | Yes, Yes |
| Alerts and Records | Yes, Yes |
| Auto Dimming Screen | Yes, Yes |
| Body Material | ABS |
| Brand | DiabloSport, DiabloSport |
| CARB (California) Compliant | No, No |
| Case Included | No |
| Category | Vehicles, Equipment, Tools, and Supplies, Vehicles, Equipment, Tools, and Supplies |
| Check Clear DTCs | Yes |
| Color Display | Yes |
| Color Touch Screen Display | Yes, Yes |
| Country of Origin (Primary) | US |
| Custom Tuning | Yes, Yes |
| Data Logging | Yes, Yes |
| Emission Code | 7, 7, Not in CA |
| Erases Fault Code | Yes, Yes |
| Fuel Type | Gas, Gasoline |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8512204040 |
| Hazardous Material Code | N |
| In Cab Monitoring | Yes |
| Instruction Manual Included | Yes, Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Part Type | Computer Chip Programmer, Computer Chip Programmer |
| Performance Tests | Yes, Yes |
| Performance Tunes | Yes, Yes |
| Pods and Mounts Available | Yes, Yes |
| Product Type | Tuning/Calibration Kit, In-Cabin Tuner |
| SDR Required Flag | N |
| Software Included | Yes, Yes |
| Speedometer | Yes, Yes |
| Sub Category | Engine Service, Engine Service |
| Touch Screen | Yes |
| Upgradable | Yes, Yes |
| Video Capable | Yes, Yes |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty Time | 1 |
| Wi-Fi Updates | Yes, Yes |
| GTIN | 00810009939511 |
