Description
CURT 184046 Brake Drum Hub Assembly for 10,000-lb. Axle – 8 on 6.5″, 5/8″ StudFor peace of mind on the road, replace your brake hub with Lippert. This brake drum hub assembly fits a 12-1/4″ x 3-3/8″ brake on a 10,000-lb. axle. It’s made from solid, durable iron and has an 8 on 6.5″ bolt pattern with a 4.75″ hub pilot and 5/8″ stud. Our brake hub assemblies include the hub drum with bearing races and wheel studs. Additionally, all our brake hub assemblies come with a limited one-year warranty on the hub components. Please consult your original equipment before purchasing. Be sure to inspect and maintain your equipment periodically for optimal performance.
- Brake hub size: 12-1/4″ x 3-3/8″
- Brake hub material: Grey iron
- Bolt pattern: 8 on 6.50″ with 4.75″ hub pilot
- Stud size: 5/8″
- Axle rating: 10,000 lbs.
- Wheel size: 16″ dual or 17.5″ single
- Limited 1-year warranty
- This item ships in a kraft box
Information:
This item ships in a kraft box
| Attributes | |
| Container Volume Cubic Feet – XA | 0.00000 |
| Container Volume Cubic Meter – XA | 0.00000 |
| Country of Origin (Primary) | CN |
| Finish | Blank |
| Finish – XA | Blank, Blank |
| Harmonized Tariff Code (Schedule B) | 8716905060 |
| Hazardous Material Code | N |
| Item Class – XA | LRV, LRV |
| Item Height – XA | 0.000, 0.000 |
| Item Length – XA | 0.000, 0.000 |
| Item Width – XA | 0.000, 0.000 |
| Life Cycle Status Code | Available Only While Supplies Last |
| Master Case Height Inches – XA | 0.000, 0.000 |
| Master Case Length Inches – XA | 0.000, 0.000 |
| Master Case Volume Cubic Feet – XA | 0.00000, 0.00000 |
| Master Case Weight Lbs – XA | 0.000, 0.000 |
| Master Case Width Inches – XA | 0.000, 0.000 |
| Material – XA | Blank, Blank |
| Mount Type Description – XA | Not Applicable, Not Applicable |
| NAFTA Preference Criterion Code | B |
| Pallet Qty – XA | 0.000, 0.000 |
| Pallet Total Height Inches – XA | 0.000, 0.000 |
| Pallet Total Weight Per – XA | 0.000, 0.000 |
| Parcel Allowed – XA | Yes, Yes |
| Product Weight – XA | 94.800, 94.800 |
| Rate Class – XA | 50.0, 50.0 |
| Retail Height – XA | 13.000, 13.000 |
| Retail Length – XA | 13.000, 13.000 |
| Retail Width – XA | 13.000, 13.000 |
| Sales Family Code – XA | TPACC, TPACC |
| Sales Family Description – XA | TRAILER PARTS AND ACCESS, TRAILER PARTS AND ACCESS |
| Sales Group Description – XA | LIPPERT HUBS AND BEARINGS, LIPPERT HUBS AND BEARINGS |
| SDR Required Flag | N |
| Shipping Weight – XA | 87.000, 87.000 |
| Side Application Type Description – XA | Not Applicable, Not Applicable |
| Tariff 301 – XA | Yes, Yes |
| Truckload Volume Cubic Feet – XA | 0.00000, 0.00000 |
| GTIN | 00848150068439 |
